TrueWay Tec MC4 Connectors, Y Connectors, Parallel Connectors

TrueWay Solar Connector, users can directly connect solar panel to inverter, without the consideration of anti-reverse device.



Application

TrueWay Tec PV connectors are widely used in solar system, from small charge controller, home use inverter system, to larger type inverter system, we offer various types of connectors, always be one of them suitable for you.

For different system, you can choose different voltage.

TrueWay Tec PV connectors are widely used in solar system, from small charge controller, home use inverter system, to larger type inverter system, we offer various types of connectors, always be one of them suitable for you.

The feature of solar connector:

1. Stable Self-Locking Structure, easy to open and close
2. The shell adopts high-strength PPO Plastic
3. Strong sealing and Waterproof connector
4. With thick copper inner core and better conductivity

Specification:

• Insulation Material: PPO

• Rated Current: 20A(4mm²）

• Rated Voltage: DC1000V

• Contact Resistance: ≤5mΩ

• Insulation Resistance: >500mΩ

• Operating Temperature range: -40℃ until+90℃

• Degree of Protection: IP67

• Flame Class: UL94-V0

• Safety Degree: Ⅱ

• Suitable Single Core Cable Section: 1.5mm² — 6mm²
